ARTEX C406-2 Series - User Manual

Questions and Answers

G
griffithjulianAug 9, 2025
Why is my ARTEX C406-2 Transmitter showing a 1-Flash error?
- J
  Jeffrey McdanielAug 9, 2025
  A 1-Flash error on your ARTEX Transmitter can be due to several reasons related to the G-switch loop or remote switch harness. Here's what you should check: * Check the remote switch harness connector at the ELT for looseness or disconnection and tighten if necessary. * Inspect the ELT connector pins for bending or breakage, and repair or replace as needed. * Look for an open jumper (internal to the remote switch harness connector at the ELT end) on connector pins 5 and 8, and repair the open jumper.
P
Paul IngramAug 14, 2025
What to do if my ARTEX Transmitter ELT will not turn off?
- M
  margaretgreeneAug 14, 2025
  If your ARTEX Transmitter ELT won't turn off, here are some possible causes and solutions: * The battery may be too low to support a 406 burst, causing the circuit to reset. Remove the battery pack to disable the ELT and then replace the battery pack. * Check the wiring continuity of the remote switch harness reset circuit and repair as necessary. * The remote switch might be defective, consider replacing it.
L
Larry SavageAug 18, 2025
What to do if my ARTEX Transmitter is showing a 5-Flash error?
- J
  Jennifer SilvaAug 18, 2025
  A 5-Flash error on your ARTEX Transmitter indicates that no navigation position data is present. To resolve this: * Ensure the aircraft navigation system is turned on. * Check the system interface wiring and connections for continuity and security. * If a 453-6500 ELT/NAV Interface is required but not installed, install it. * Reprogram to short message.
L
Laura HodgeAug 25, 2025
Why is my ARTEX C406-2 showing a 7-Flash error?
- K
  Krista BrownAug 25, 2025
  A 7-Flash error on your ARTEX Transmitter indicates a battery problem. If the operating time has exceeded 1 hour, replace the battery pack.
M
mallory99Aug 29, 2025
How to fix ARTEX Transmitter remote switch LED always on?
- B
  Brett MoralesAug 29, 2025
  If the remote switch LED on your ARTEX Transmitter is always on (steady), it could be due to improper wiring or a short circuit. Verify the wiring, check for frayed insulation, and verify the integrity of all crimp and solder connections.
C
colinalvarezNov 3, 2025
What to do if my ARTEX Transmitter shows a 3-Flash error?
- C
  carolinecervantesNov 3, 2025
  A 3-Flash error on your ARTEX Transmitter indicates a potential 406 MHz transmission problem. Here's what you can do: * Verify the coax cable/antenna is connected and in good condition. Perform a continuity check of the center conductor and shield, and check for a shorted cable. * Check for intermittent connections in the coax cable. * Use a VSWR meter to check the antenna. Look for opens, shorts, or a resistive ground plane connection. * Adjust the antenna coax cable length by 4 to 6 inches to address impedance issues. * Ensure a ground plane of at least 12 inches in diameter is present. * Keep the antenna at least 10-12 inches away from upright metal structures to prevent re-radiation. * Check if the battery is low. * Verify the 406 MHz programming. If these steps don't...

Summary

NOTICES

AIRWORTHINESS LIMITATIONS

Details FAA approved airworthiness limitations and required inspections.

IMPORTANT NOTICE

ACR Electronics responsibility for manual distribution and revisions.

RECORD OF REVISIONS

SERVICE BULLETIN LIST

LIST OF EFFECTIVE PAGES

INTRODUCTION

1. Manual Usage

Guidance on manual usage, including general information and application.

2. Model Descriptions

Describes the C406-2 and C406-2HM ELT models.

3. Approvals

Lists the approvals for the C406-2 and C406-2HM ELTs.

4. Frequency Allocations

Details the 406 MHz transmitter frequency and allocations.

5. List of Acronyms, Abbreviations, and Definitions

Provides definitions for terms used in the manual.

6. References

Lists regulatory documents and other references.

REMOVAL

1. ELT

Procedure for removing the ELT unit from the aircraft.

2. Battery

Procedure for removing the battery pack.

3. Material or Equipment Return

Information and authorization for returning material or equipment.

INSTALLATION

1. Regulatory Requirements and Guidelines

Requirements for ELT installation in various aircraft and countries.

2. Mounting Tray

Guidelines for selecting and installing the ELT mounting tray.

3. Antenna

Selection and installation procedures for approved antennas.

4. Remote Switch

Location and installation of the cockpit remote switch.

5. Buzzer

Location and installation of the audible buzzer.

6. Wiring

General considerations and recommendations for wiring.

APPENDIX A - ELT REGISTRATION

1. Background Information

Information on Hex ID code and reason for ELT registration.

2. Registration

Aircraft owner's responsibility and required information for registration.

ILLUSTRATED PARTS LIST

1. Introduction

Purpose and usage guide for the illustrated parts list.

2. Manufacturer Name and Address

Contact information for ordering parts.

3. Explanation of Detailed Parts List Entries

Explains how to interpret entries in the detailed parts list.

LIST OF FIGURES

DESCRIPTION AND OPERATION

1. Description

Details the ELT's functional overview and components.

2. Operation

A. Operational Overview

Overview of the ELT's operational flow and states.

3. Specifications

A. Environmental and Physical

Lists environmental and physical specifications for the ELT.

TEST AND FAULT ISOLATION

1. Inspection and Test Regulatory Requirements

Regulatory requirements for ELT inspection and testing.

2. Inspection and Test Procedures

Detailed procedures for ELT inspection and testing.

H. Performance Testing Setup

Setup for performance testing of the ELT.

N. Current Draw Test - Item 5 f

Procedure for testing the ELT's current draw.

O. Digital Message Verification - Item 5 g

Procedure for verifying the ELT's digital message.

P. ELT Reset Check - Item 5 h

Procedure for checking the ELT reset function.

Q. Installed Transmitter Test - Item 6

Procedure for testing the installed ELT transmitter.

R. Antenna Test - Item 7

Procedure for testing the ELT antenna.

S. Inspection and Test Documentation - Item 8

Requirements for documenting ELT inspection and testing.

3. Fault Isolation

A. Self-Test Error Troubleshooting Guidelines

Troubleshooting guide for ELT self-test error codes.

B. ELT Troubleshooting Guidelines

Guidelines for troubleshooting ELT installation and operational issues.

7. ELT Installation

A. Installation and Test

Steps for installing and testing the ELT unit.

B. Harness ELT Receptacle Sealing

Procedure to seal the ELT harness receptacle to prevent moisture.

C. Installation Documentation

Documentation requirements for ELT installation.

8. Battery Pack Installation

A. Battery Reinstallation

Procedure for reinstalling an existing battery pack.

B. New Battery Installation

Procedure for installing a new replacement battery pack.

9. Helicopter Installations - Special Considerations

A. Background

Background on mounting ELTs in helicopters.

B. Recommendations

ACR Electronics recommendations for helicopter installations.

C. Orientation

Guidance on orienting the ELT for helicopter installations.

4. Detailed Parts List
