12. The Surgical monitor will display one of the
following.
When the White Balance has been
completed successfully, a Green Check
Mark with WHITE BALANCE below will
be shown on screen.
Figure 24-White Balance OK
When the White Balance has not been
completed successfully, a Red X with
WHITE BALANCE below will be shown
on screen.
Figure 25-White Balance Fail
13. If the White Balance Operation has been
successful, the camera will enter the
Surgical Ready Mode and be ready for
surgical operation.
14. If the White Balance Operation has not
been successful, you must move the Tip
of the Endoscope closer or farther from
the White Gauze until the operation can
be completed successfully.
15. Once the White Balance Operation has
been successfully completed, the
Camera Head buttons will function as
defined on the Synergy
HD3
Initial Screen
Figure 23.
