950-0027-01B 38 of 55
2.6.1 The Synergy HD3 Camera Control Unit [AR-3200-0001T] can be used in the
Picture in Picture Mode to display a Picture in Picture [PIP] on the surgical
monitor.
2.6.2 Second video source for PIP is connected to the Camera Controller’s DVI
Input.
2.6.3 The Synergy HD3 Camera Control Unit [AR-3200-0001T] will accept ONLY
DVI 1080P/60 video.
2.6.3.1 This can be accomplished by connecting a DVI 1080P/60 VIDEO
SOURCE directly to the Camera Control Unit’s DVI Input, or by
using the optional AR-3210-1005 Video Input/Output Converter.
2.6.3.2 The AR-3210-1005 Video Input/Output Converter is connected to
the Camera Control Unit DVI Input, and the NON 1080P/60 video
source is connected to the AR-3210-1005, which will convert the
source to the needed 1080P/60 video format for PIP.
2.6.4 The Tablet Data Input Device is utilized to configure PIP.
2.6.4.1 PIP Enable/Disable
2.6.4.2 PIP Location
2.6.4.3 Still Capture from External Source
2.6.4.4 Streaming Video Capture from External Source
