Arthrex SynergyHD3 User Manual

950-0027-01B 40 of 55
3.3.2 Cleaning the Camera Head
CAUTIONS:
 If the camera head is dented or damaged, or if the connector jacket is cut, DO NOT
autoclave or immerse in liquid (water, chemical disinfectants or sterilants, etc.). Notify
your Arthrex Sales Representative.
 Do not place the camera head or accessories in an ultrasonic cleaner or washer/sterilizer.
Preparation for Cleaning and Sterilization
Immediately after use, place the camera head assembly in a container and soak with neutral pH (PH 6.0 –
8.0) enzymatic cleaning solution (e.g. Enzol, Metrizyme or equivalent diluted to proper concentrations per
manufacturer’s instructions), in order to prevent blood, protein and other contaminants from drying onto the
camera head.
3.3.2.1 Automated Cleaning
 Use only washers according to the International Standard ISO 15883.
 Refer to the washer’s instruction manual.
1. Transfer the camera had into the washer for processing.
2. Make sure that the camera head has been securely fixed to the unit’s trays or baskets. Make sure
that the camera head does not touch other instruments.
3. Do not overload the washer.
4. Remove the camera heads immediately after the automatic procedure has stopped.
5. Set up washer for the wash cycle listed below.
Automatic Washer Cycle Definition
Phase
Recirculation Time
(Minutes)
Temperature
Detergent Type and
Concentration.
Pre-Wash 1
02:00
Cold Tap Water
NA
Enzyme Wash
03:00
Hot tap water
Enzol® 1oz/gallon
Rinse 1
00:15
Hot tap Water 60
o
C
NA
Drying
06:00
90
o
C
NA
3.3.2.2 Manual Cleaning
CAUTION: Wear protective gloves, clothing and face mask for cleaning of contaminated equipment.
1. Immediately after use, Rinse the camera head under cool running tap water to remove the gross
soil. Use a soft bristled brush to aid in the removal of soil paying particular attention to hard-to-
clean areas.
2. Prepare a neutral enzymatic detergent, such as Enzol®, using tap water at 1 oz/gallon.
3. Fully immerse the camera head in the prepared solution and allow it to soak for a minimum of 10
minutes. Flush hard to reach areas to ensure all soil is removed. While soaking activate movable
parts.
4. After soaking, use a soft bristled nylon brush to remove all visible evidence of debris and soil. Pay
close attention to the card edge connector.
5. Rinse the camera head by immersing it in a basin of warm tap water. Allow the camera head to
sit in the water for a minimum of 1 minute, while soaking activate movable parts. .
