950-0027-01B 46 of 55
Table 4: Safety, Classifications
Classification of Equipment
Parameter Value
According to protection against electric shock.
Class I [Grounded]
According to degree of protection against
electric shock.
Applied part is Type BF
According to Degree of protection against
harmful ingress of water.
Camera Control Units are Ordinary [IPX-0] no
protection.
Camera Head is IXP-7 [Protected against
temporary immersion in water]
According to the degree of safety in the
presence of Flammable Anesthetics
Equipment is NOT suitable for use in the
presence of flammable anesthetics.
According to the mode of operation.
Continuous
Table 5: Specifications
Parameter
Parameter Value
Power Requirements
Rated Voltage: 100 240 V~
Supply Frequency: 50-60 Hz
Power Input: 140 VA
Fuses: No user serviceable fuses
Video Outputs
3G-SDI [1080P] Video: 59.94 Hz, Progressive, SMPTE 425 Standard
DVI [1080P]: 1920 X 1080 Pixels Progressive Scan [1080P]
Vertical Scanning
Frequency
59.94 Hz
Signal to Noise Ratio
> 50 -dB
White Balance Range;
Integrated Optics Head
2000 to 10,000 K
White Balance Range
:C-Mount Head
3053 to 10,000 K
CCU Dimensions
Approximately: 16” [W] x 5” [H] x 13.5” [D]
40.6 cm [W] x 12.7 cm [H] x 34.3 cm [D]
CCU Weight
Approximately: 18 pounds
Camera Head
Dimensions
AR-3210-0001
Approximately
4.75” [L] x 2.0” [W], x 2.0 [H]
12 cm [L] x 5 cm [W] x 5 cm [H]
AR-3210-0003
Approximately:
3.125” [L] x 1.5” [W], x 2.0 [H]
8 cm [L] x 4 cm [W] x 5 cm [H]
AR-3210-0004
Approximately:
3.125” [L] x 1.5” [W], x 2.0 [H]
8 cm [L] x 4 cm [W] x 5 cm [H]
AR-3210-0007
Approximately:
3.125” [L] x 1.5” [W], x 2.0 [H]
8 cm [L] x 4 cm [W] x 5 cm [H]
