4 Aruba Instant On AP17 Access Points | Installation Guide
Figure 3 Attaching the Mount Bracket to a Wall
6. Slide the holder of the AP into the opening of the mount bracket and use the M6x45 screw included in the
package to fix the AP to the mount bracket.
Figure 4 Attaching the AP to the Mount Bracket
