Aruba 560 Series Outdoor Access Points | Installation Guide 3
Table 2 560 Series LED Meanings during Operation
Ethernet Port
The 560 Series access point is equipped with one Ethernet port (E0). The Ethernet port is 100/1000Base-T auto-
sensing MDI/MDX, which supports uplink connectivity when linked by an Ethernet cable.
Power
The Ethernet port supports PoE-in, allowing the AP to draw power from an 802.3af/802.3at PoE power
source.The 560 Series access point supports the Intelligent Power Monitoring (IPM) feature that actively
measures the power utilization of the AP and dynamically adapts to the power budget.
Table 3 lists operational restrictions when the AP is powered by different power options.
Table 3 Power Options and Operational Restriction
Grounding Point
Always remember to protect the access point by installing grounding lines. The ground connection must be
complete before connecting power to the access point enclosure.
USB Type-C Console Port
Use the included USB Type-C console cable to connect the access point to a laptop or a serial terminal for direct
management.
Reset Button
The reset button can be used to reset the access point to factory default settings or turn off/on the LED display.
There are two ways to reset the access point to factory default settings:
Reset the AP during normal operation
Press and hold down the reset button using a small, narrow object such as a paper clip for more than 10
seconds during normal operation.
LED Color/State Meaning
System LED Solid Red General fault - Immediate attention required
One blink off every 3
seconds
Radio 0 fault (5 GHz)
Two quick blink off 0.5
seconds apart cycled every
3 seconds
Radio 1 fault (2.4GHz)
Power Source IPM Restrictions
802.3at PoE n/a No restrictions, all capabilities available.
802.3af PoE enabled AP starts up in unrestricted mode, but may dynamically
apply restrictions depending on the PoE budget and actual
power.
802.3af PoE disabled 2.4GHz radio is restricted to 1 spatial stream.
You need a proper 8mm allen or hex key to open the cover of the USB Console port.
