USER MANUAL [1.4]
Page 39
ATTENTION: THE KUSS MODE COMBINED WITH LSS 485 MODE, WHICH
ALLOWS SIMULTANEOUSLY USING BOTH FLSs AND KUSS AT THE BUS
ATTENTION: THE PASSENGER TRAFFIC FLOW MODE COMBINED WITH LSS 485
MODE, WHICH ALLOWS SIMULTANEOUSLY USING BOTH FLSs AND PASSENGER TRAFFIC
FLOW AT THE BUS
Working with the signal pick-up device controller
Data are transmitted from KUSS to the server in the form of two tags:
155
KUSS_L
Filling capacity in ml
156
0xNNTTTTTT
KUSS_N,
KUSS_T
Filling operation number and filling operation duration
Working with the passenger traffic flow sensor PP-01
The tracker can simultaneously work with 4 passenger traffic flow sensors, which must have
different network addresses within the range from 01 to 04.
Data transmission to the server takes place in tag No 190 virtual sensors:
Sub-tag 0 the number of entries from the sensor with the address 01
Sub-tag 1 the number of exits from the sensor with the address 01
Sub-tag 2 the number of entries from the sensor with the address 02
Sub-tag 3 the number of exits from the sensor with the address 02
Sub-tag 4 the number of entries from the sensor with the address 03
Sub-tag 5 the number of exits from the sensor with the address 03
Sub-tag 6 the number of entries from the sensor with the address 04
Sub-tag 7 the number of exits from the sensor with the address 04
Sub-tag 8 indicates the door status of each sensor bitwise
