TD 92989EN
15 October 2014 / Ver. B
Installation Guide
IP-DECT Base Station & IP-DECT Gateway
13
Software
The software in the BS3x0 can be updated by downloading new software without
dis
connecting the equipment. The new software is stored in flash memory. For
information on how to update the software in the BS3x0, see the applicable Installation
and Operation Manual for the BS3x0.
Connectors
• Two 8-pin RJ45 modular jacks for data and powering
• A 6-pin RJ12 modular jack for factory testing
LEDs
Status of LED1 (lower LED) Description
Steady Green Power LED
Status of LED2 (upper LED) Description
Not lit Base station operational and no traffic on the
base station.
Flashing green Fully occupied with traffic.
Steady green Base station operational and traffic on the base
station.
Flashing amber Software is being downloaded to the base station
Steady amber Base station is OK, but not available (self-test, not
initialized, no communication with IPBL)
