ASCOM PCR Charging Rack - Module Mounting Procedures

TD 92356GB
2007-03-16/ Ver. C
Installation Guide
PCR Charging Rack
6
3.3 Mounting the Power Supply Module
IMPORTANT: The Power Supply module must be mounted horizontally and with the clips
down.
Figure 4.
002
Figure 4. The Power Supply module must be mounted horizontally.
3.4 Mounting the Charging Rack Module
Figure 5.
UP
UP
PCR
OTHERS
UP
UP
PCR
OTHERS
023
Figure 5. The Charging Rack modules must be mounted with the arrow marked "UP
PCR" upwards.
