TD 91684GB
16 April 2015 / Ver. G
Installation Guide
T942C and T942C/2 Central Unit
26
1 Select the Numbers tab
2 Right-click the T942C Central Unit to be configure in the list.
3 Select "Edit parameters".
3.2.1 Set License
This chapters describes how to set the license on a Central Unit delivered with factory
settings. That is, a Central Unit without any parameters set. A valid license is required to set
the parameters in the Central Unit.
1 Set section 5 on SW02 to ON. This is the setting for unlicensing mode.
2 Restart T942C by pressing push button S01.
The function indicator will flash red after the start up.
3 Connect the Central Unit’s to the computer running PDM. That is, attach the cable
between the connector J09 to the computer’s COM-port.
4In the Edit Parameter dialog window in PDM, select "Licence".
5In the License text field, enter the license.
6 Set section 5 on SW02 to OFF and press the reboot button on the Central Unit. It
should now start in normal mode.
