Ascon Tecnologic - K Series - ENGINEERING MANUAL - PAG. 27
Appendix A
]
InP Group (Inputs Parameters)
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
1 HcFG
Parameter available by serial link.
It shows the current hardware
0
TC/RTD
TC/PTC
Current
Voltage
Accor-
ding to
Hardw.
Not vis.
2 SEnS
Sensor selection (according to hardware)
TC, Pt100 input
0
J, crAL, S, r, t, ir.J, ir.cA, Pt1, 0.50 (mV), 0.60 (mV) 12.60 (mV)
J
A-4
TC, PTC, NTC input
J, crAL, S, r, t, Ir.J, Ir.cA, Ptc, ntc, 0.50 (mV), 0.60 (mV),
12.60 (mV)
Ptc
I input 0.20 (mA), 4.20 (mA) 4.20
V input 0.5(V), 1.5(V), 0.10(V), 2.10(V), 0.1 (V) 0.10
3 dP Decimal figures 0 0... 3 0 A-5
4 SSc Initial scale readout dP From -1999 to FSC (E.U.) -1999 A-6
5 FSc Final scale readout dP From SSc to 9999 (E.U.) 9999 A-7
6 unit Engineering unit 0 °c or °F 0 = °c A-8
7 FiL Digital filter on the measured value 1 From 0( oFF) to 20.0 (s) 1.0 C-0
8 inE
Selection of the Sensor Out of Range
type that will enable the safety output
value
0
or Over-range
ur Under-range
our Over and Under
our C-0
9 oPE Safety output value 0 -100... 100 (%) 0 C-0
10 diF1 Digital input 1 function 0
oFF No function
1 Alarm Reset
2 Alarm acknowledge (ACK)
3 Hold of the measured value
4 Stand by mode
5 HEAt with SP1 and CooL with “SP2”
6 Timer run/hold/reset [transition]
7 Timer run [transition]
8 Timer reset [transition]
9 Timer run/hold [Status]
10 Program run
11 Program reset
12 Program hold
13 Program run/hold
14 Program run/reset
15 Instrument in Manual mode
16 Sequential set point selection
17 SP1/SP2 selection
18 Set point Binary selection
19 Digital inputs in parallel to
and keys
20 Timer Run/Reset
nonE A-13
11 diF2 Digital input 2 function 0 nonE A-14
]
Out Group (Outputs Parameters)
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
12 o1F Out 1 function 0
NonE Output not used,
H.rEG Heating output
c.rEG Cooling output
AL Alarm output
t.out Timer output
t.HoF Timer output OFF when timer in hold
P.End Program end indicator
P.HLd Program hold indicator
P. uit Program wait indicator
P.run Program run indicator
P.Et1 Program Event 1
P.Et2 Program Event 2
or.bo Out-of-range or burn out indicator
P.FAL Power failure indicator
bo.PF
Out-of-range, burn out and Power failure indicator
diF.1 The output repeats the digital input 1 status
diF.2 The output repeats the digital input 2 status
St.bY Stand by status indicator
on Out 1 forced to ON
H.reg A-16
