Ascon Tecnologic - K Series - ENGINEERING MANUAL - PAG. 28
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
13 o1AL Alarms linked up with the out 1 0
0... 31:
+1 Alarm 1
+2 Alarm 2
+4 Alarm 3
+8 Loop break alarm
+ 16 Sensor break (burn out)
AL1 A-17
14 o1Ac Out 1 action 0
dir Direct action
rEU Reverse action
dir.r Direct with reversed LED
ReU.r Reverse with reversed LED
dir C-0
15 o2F Out 2 function 0
NonE Output not used
H.rEG Heating output
c.rEG Cooling output
AL Alarm output
t.out Timer output
t.HoF Timer output OFF when timer in hold
P.End Program end indicator
P.HLd Program hold indicator
P. uit Program wait indicator
P.run Program run indicator
P.Et1 Program Event 1
P.Et2 Program Event 2
or.bo Out-of-range or burn out indicator
P.FAL Power failure indicator
bo.PF O ut-of-range, burn out and Power failure indicator
diF.1 The output repeats the digital input 1 status
diF.2 The output repeats the digital input 2 status
St.bY Stand by status indicator
on Out 2 forced to ON
AL A-19
16 o2AL Alarms linked up with the out 2 0
0... 31:
+1 Alarm 1
+2 Alarm 2
+4 Alarm 3
+8 Loop break alarm
+ 16 Sensor break (burn out)
AL1 A-20
17 o2Ac Out 2 action 0
dir Direct action
rEU Reverse action
dir.r Direct with reversed LED
ReU.r Reverse with reversed LED
dir C-0
18 o3F Out 3 function 0
NonE Output not used
H.rEG Heating output
c.rEG Cooling output
AL Alarm output
t.out Timer output
t.HoF Timer output OFF when timer in hold
P.End Program end indicator
P.HLd Program hold indicator
P. uit Program wait indicator
P.run Program run indicator
P.Et1 Program Event 1
P.Et2 Program Event 2
or.bo Out-of-range or burn out indicator
P.FAL Power failure indicator
bo.PF
Out-of-range, burn out and Power failure indicator
diF.1 The output repeats the digital input 1 status
diF.2 The output repeats the digital input 2 status
St.bY Stand by status indicator
on Out 3 forced to ON
AL A-22
19 o3AL Alarms linked up with the out 3 0
0... 31:
+1 Alarm 1
+2 Alarm 2
+4 Alarm 3
+8 Loop break alarm
+ 16 Sensor break (burn out)
AL2 A-23
20 o3Ac Out 3 action 0
dir Direct action
rEU Reverse action
dir.r Direct with reversed LED
ReU.r Reverse with reversed LED
dir C-0
