Ascon Tecnologic - K Series - ENGINEERING MANUAL - PAG. 32
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
58 Pb Proportional band dP 0... 9999 (E.U.) 50 A-28
59 int Integral time 0 From 0 (oFF) to 9999 (s) 200 A-29
60 dEr Derivative time 0 From 0 (oFF) to 9999 (s) 50 A-30
61 Fuoc Fuzzy overshoot control 2 0.00... 2.00 0.50 A-31
62 H.Act Heating output actuator 0
SSr SSR
rELY Relay
SLou Slow actuators
SSr A-32
63 tcrH Heating output cycle time 1 0.1... 130.0 (s) 20.0 C-0
64 PrAt
Power ratio between heating and cool-
ing action
2 0.01... 99.99 1.00 A-34
65 c.Act Cooling output actuator 0
SSr SSR
rELY Relay
SLou Slow actuators
SSr A-35
66 tcrc Cooling output cycle time 1 0.1... 130.0 (s) 20.0 C-0
67 rS Manual reset (Integral pre-load) 1 -100.0... 100.0 (%) 0.0 C-0
68 od Delay at power ON 2 From 0.00 (oFF) to 99.59 (hh.mm) oFF C-0
69 St.P
Maximum power output used during
soft start
0 -100... +100 (%) 0 C-0
70 SSt Soft start time 2 From 0.00 (oFF) to 8.00 (inF) (hh.mm) oFF C-0
71 SStH Threshold for soft start disabling dP -1999... +9999 (E.U.) 9999 C-0
]
SP Group (Set Point Parameters)
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
72 nSP Number of used set points 0 1... 4 1 A-38
73 SPLL Minimum set point value dP From -1999 to SPHL -1999 A-39
74 SPHL Maximum set point value dP From SPLL to 9999 9999 A-40
75 SP 1 Set point 1 dP From SPLL to SPLH 0 O-41
76 SP 2 Set point 2 dP From SPLL to SPLH 0 O-42
77 SP 3 Set point 3 dP From SPLL to SPLH 0 O-43
78 SP 4 Set point 4 dP From SPLL to SPLH 0 O-44
79 SPAt Selection of the active set point. 0 From 1 (SP 1) to nSP 1 O-45
80 SP.rt Remote set point type 0
RSP The value coming from serial link is used as
remote set point
trin The value will be added to the local set point
selected by SPAt and the sum becomes the
operative set point
PErc
The value will be scaled on the input range
and this value will be used as remote set point
trin C-0
81 SP.Lr Local/remote set point selection 0
Loc local
rEn remote
Loc C-0
82 SP.u
Rate of rise for POSITIVE set point change 2 0.01... 100.00 (inF) Engineering units per minute inF C-0
83 SP.d Rate of rise for NEGATIVE set point change 2 0.01... 100.00 (inF) Engineering units per minute inF C-0
]
Tin Group (Timer Function Parameters)
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
84 tr.F Independent timer function 0
NonE Timer not used
i.d.A Delayed start timer
i.uP.d Delayed start at power ON
i.d.d Feed-through timer
i.P.L Asymmetrical oscillator with start in OFF
i.L.P Asymmetrical oscillator with start in ON
nonE A-62
85 tr.u Timer unit 0
hh.nn Hours and minutes
nn.SS Minutes and seconds
SSS.d Second and tenth of seconds
nn.SS A-63
86 tr.t1 Time 1
2 00.01... 99.59 when tr.u < 2
1.00 A-64
1 000.1... 995.9 when tr.u = 2
87 tr.t2 Time 2
2 When tr.u < 2: From 00.00 (oFF) to 99.59 (inF)
1.00 A-65
1 When tr.u = 2: From 000.0 (oFF) to 995.9 (inF)
88 tr.St Timer status 0
rES Timer reset
run Timer run
HoLd Timer hold
rES C-0
