Ascon Tecnologic - K Series - ENGINEERING MANUAL - PAG. 34
]
PAn Group (HMI Operator Parameters)
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
114 PAS2 Password level 2 0
0 oFF
1... 999
20 A-93
115 PAS3 Password level 3 0 3... 999 30 C-0
116 uSrb
button function during run time
0
nonE Not used
tunE Starts auto tuning functions
oPLo Manual mode (oPLo)
AAc Alarm reset
ASi Alarm acknowledge
chSP Sequential set point selection
St.by Stand-by mode
Str.t Run/hold/reset timer
P.run Program start
P.rES program reset
P.r.H.r Run/hold/reset program
nonE A-94
117 diSP Secondary display management 0
nonE Standard display
Pou Power output
SPF Final set point
Spo Operative set point
AL1 Alarm 1 threshold
AL2 Alarm 2 threshold
AL3 Alarm 3 threshold
Pr.tu Program time up
Pr.td Program time down
P.t.tu Program total time up
P.t.td Program total time down
ti.uP Timer time up
ti.du Timer time down
PErc Percent of the power output used during soft
start (when the soft start time is equal to in-
finite, the limit is always active; can be used
also when ON/OFF control is selected)
nonE A-95
119 FiLd Filter on the displayed value 1
0.0 oFF
0.1... 20.0
oFF C-0
120 dSPu Status of the instrument at power ON 0
AS.Pr Starts in the same way it was prior to the
power down
Auto Starts in Auto mode
oP.0 Starts in manual mode with a power output
equal to zero
St.bY Starts in stand-by mode
AS.Pr C-0
121 oPr.E Operative mode enabling 0
ALL All
Au.oP Autp or manual (oPLo) only
Au.Sb Auto and Stand by only
ALL C-0
122 oPEr Operative mode selection 0
Auto Automatic
oPLo Manual
St.by Stand-by
Auto O-1
]
Ser Group (Serial link Parameters)
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
123 Add Address 0
0 (oFF)
1... 254
1 C-0
124 bAud Baud rate 0
1200
2400
9600
19.2
38.4
9600 C-0
125 trSP
Selection of the value to be retransmit-
ted (Master)
0
nonE Not used
rSP Operative set point
PErc Current power output (%)
nonE C-0
