Ascon Tecnologic - K Series - ENGINEERING MANUAL -Vr. 9.0 PAG. 28
]
Out Group (Outputs Parameters)
no.
Para-
meter
Description Dec. Range Default
Vis.
Promo.
12 o1F Out 1 function 0
NonE = Output not used,
H.rEG = Heating output
c.rEG = Cooling output
AL = Alarm output
t.out = Timer output
t.HoF = Timer output OFF when timer in hold
P.End = Program end indicator
P.HLd = Program hold indicator
P. uit = Program wait indicator
P.run = Program run indicator
P.Et1 = Program Event 1
P.Et2 = Program Event 2
or.bo = Out-of-range or burn out indicator
P.FAL = Power failure indicator
bo.PF =
Out-of-range, burn out and Power failure indicator
diF.1 = The output repeats the digital input 1 status
diF.2 = The output repeats the digital input 2 status
St.bY = Stand by status indicator
on = Out 1 forced to ON
H.reg A-16
13 o1AL Alarms linked up with the out 1 0
0... 31:
+1 = Alarm 1
+2 = Alarm 2
+4 = Alarm 3
+8 = Loop break alarm
+ 16 = Sensor break (burn out)
AL1 A-17
14 o1Ac Out 1 action 0
dir = Direct action
rEU = Reverse action
dir.r = Direct with reversed LED
ReU.r = Reverse with reversed LED
dir C-0
15 o2F Out 2 function 0
NonE = Output not used
H.rEG = Heating output
c.rEG = Cooling output
AL = Alarm output
t.out = Timer output
t.HoF = Timer output OFF when timer in hold
P.End = Program end indicator
P.HLd = Program hold indicator
P. uit = Program wait indicator
P.run = Program run indicator
P.Et1 = Program Event 1
P.Et2 = Program Event 2
or.bo = Out-of-range or burn out indicator
P.FAL = Power failure indicator
bo.PF = O
ut-of-range, burn out and Power failure indicator
diF.1 = The output repeats the digital input 1 status
diF.2 = The output repeats the digital input 2 status
St.bY = Stand by status indicator
on = Out 2 forced to ON
AL A-19
16 o2AL Alarms linked up with the out 2 0
0... 31:
+1 = Alarm 1
+2 = Alarm 2
+4 = Alarm 3
+8 = Loop break alarm
+ 16 = Sensor break (burn out)
AL1 A-20
17 o2Ac Out 2 action 0
dir = Direct action
rEU = Reverse action
dir.r = Direct with reversed LED
ReU.r = Reverse with reversed LED
dir C-0
