4 - Operation
With the access level Edit, the user
defines which groups and para-
meters are accessible to the oper-
ator
After selecting and confirming the
access level Edit, enter in the para-
meters menu.
The code of the access level is dis-
played on the front panel.
Press the
$ and % keys to
select the proper level.
The parameters in the access level
fast are recalled on the front panel
through the procedure of fast para-
meter access illustrated in par. 5.2
pag 29. The maximum number of fast
parameters is 10.
At the end of the parameter list of the
selected group, the controller quits
from the Edit access level.
Therefore, the Edit level must be
selected for each group of para-
meters
The access level of groups and para-
meters, is activated through
Ac.le
Oper
4.4 ACCESS LEVELS PASSWORD CALIBRATION
Access
level operator
Confirm
Group of parameters Code Access level
read
Visible
Hide
Not visible
Parameters Code Access level
AItr
Visible and changeable
fast
Included in “Fast view”
read
Visible only
Hide
Not visible and not changeable
Menu
pId
p.b.
35.0
EHec
load
EHec
stor
potH
EHec
C.pot
potl
O
255
Calibrate
the potentiometer
(if present)
The valve
go to low scale
The valve
go to full scale
Load the data
from Memory chip
Download the data
to Memory chip
When the indication
(the valve) is stopped,
confirm the calibration
value using
$ or %
Confirm and
return back to
the Operator
mode
