ASD Document 600541 Rev. G 2 TerraSpec® User Manual
www.asdi.com Chapter 1 Introduction
1.1 Hardware Specifications
This section contains details about the TerraSpec spectrometer.
1.1.1 Physical Specifications
• Durable satin powder coat finish with orange urethane end-caps and
handles
• All vital components are in a dust-proof enclosure and EMI sealed
• Adjustable fiber optic to instrument spacer
1.1.2 Power Input and Output
Height 12.7 cm 5 inches
Width 35.6 cm 14.5 inches
Depth 29.2 cm 11.5 inches
Weight 5.6 kg 12 lbs
AC Power Supply Type Auto ranging, Switching, SELV
AC Input 90-240 VAC, 50/60 Hz
DC Input +12 VDC, 60 W
Accessory Power Port
(front of instrument)
Output, +12 VDC, 19.2 W (max).
