SECTION 2 - Description
2.1 Product description
Ubiquity Router is a hardware device able to provide the remote assistance ser-
vices as a standalone solution, allowing to use Ubiquity in all those situations
where for any reason the software solution is not an option. Ubiquity Router
device applies to the automation network with zero impact on the actual devic-
es. No changes are requested to the configuration of any of the existing devices.
Ubiquity Router implements a specific variant of Ubiquity Runtime; from the
functional point of view this is equivalent to the standard Runtime
2.2 Key features
 ASEM Ubiquity Router runtime on Microsoft Windows Embedded
Compact 7.
 Full compatibility with standard Ubiquity software functions (see Ubiq-
uity Control Center on-line manual for further information).
 ARM Cortex A8 processor (1,0 GHz, 800MHz for ET version).
 512MB RAM DDR3-800
 2/4GB eMMC memory, file system organization for data storage
 Ethernet interface 10/100 Mbps WAN for Internet connection.
 Ethernet interface 100 Mbps LAN for the automation network.
 2G/3G/3G+ modem for WAN mobile network connection (RK11 and
RM11 models)
 RS-232/RS-485/RS-422 Optical isolated serial port with MPI support up
to 187 Kbit/s.
 USB 2.0 interface for system configuration and updates.
 Front panel LEDs for device status and operation report.
 24 VDC Digital input to control Ubiquity Router device WAN connection
activation.
 24 VDC Digital input for Ubiquity Router device software reset.
 Digital output to report the status of the WAN connection to the Ubiq-
uity Server Infrastructure.
 Digital output to report remote the presence of a Control Center con-
nection (Remote assistance service running)
 Magnetic Stainless steel case.
 DIN rail book mounting and wall book mounting.
 Protection Rating: IP 20
 Four models with different features:
o RK10 systems support standard remote assistance features
o RK11 systems provide remote assistance features with addi-
tional integrated 2G/3G/3G+ modem for internet connectivity
o RM10 systems combine standard remote assistance with data
monitoring functions including data logging, alarms notifica-
tion and web HMI
o RM11 systems combine standard remote assistance with data
monitoring functions including data logging, alarms notifica-
tion, web HMI with additional integrated 2G/3G/3G+ modem
for internet connectivity and SMS notification
