67
Figure 60
Wall mount antenna drawing dimensions
6.5 Wall mount antenna drawing dimensions
1
Main bracket
2
Back bracket
3
3”8L screw
4
Cap
5
4”25L screw
6
6”24L wall mount stud
7
CFD 200 cable
8
SMA(M) ST
9
Heat shrink tube
10
Housing
11
Flexible whip
