-4-
ASSEMBLY INSTRUCTIONS
Blower Assembly
THE BLOWER ASSEMBLY MUST BE DISCONNECTED FROM THE SOURCE OF ELECTRICAL SUPPLY BEFORE ATTEMPTING
THE INSTALLATION.
THE BLOWER ASSEMBLY IS INTENDED FOR USE ONLY WITH A STOVE THAT IS MARKED TO INDICATE SUCH USE.
DO NOT ROUTE THE SUPPLY CORD NEAR OR ACROSS HOT SURFACES!
Step 1.
Fix the assembly to the back of the stove with the four screws provided.
PARTS LIST
QTY
TITLE
PART NO
ITEM
13/8 x 1-1/4 ROLL PIN835061
4
10-24 X 3/8 PH PN HD MS832022
47/32 ID X 1/2 OD X 3/64 FL W832783
5 FT5/8 ROPE GASKET880664
1DOOR GLASS (40564)891813
5
4 FTGASKET, WINDOW, .125 x 1 W/PSA 880876
2RETAINER, BOTTOM GLASS25465
7
1
DOOR,RETANGULAR - LARGE
405698
AR
SEALANT, SILICONE - BLACK
892849
1
PAINTED DOOR HANDLE
2569210
10
CUT ENDS OF GALSS GASKET SHALL
MEET AT THE BOTTOM, CENTER OF THE GLASS.
CUT ENDS OF GASKET SHALL
MEET BETWEEN HINGE LUGS.
1
8
4 9
6
5
3
2
7
ASH PAN ASSEMBLY
Remove ash pan from rebox. Under the rebox, there are two brackets; Slide the ash pan into these brackets.
PARTS LIST
QTY
TITLE
PART NO
ITEM
13/8 x 1-1/4 ROLL PIN835061
4
10-24 X 3/8 PH PN HD MS832022
47/32 ID X 1/2 OD X 3/64 FL W832783
5 FT5/8 ROPE GASKET880664
1DOOR GLASS (40564)891813
5
4 FTGASKET, WINDOW, .125 x 1 W/PSA 880876
2RETAINER, BOTTOM GLASS25465
7
1
DOOR,RETANGULAR - LARGE
405698
AR
SEALANT, SILICONE - BLACK
892849
1
PAINTED DOOR HANDLE
2569210
10
CUT ENDS OF GALSS GASKET SHALL
MEET AT THE BOTTOM, CENTER OF THE GLASS.
CUT ENDS OF GASKET SHALL
MEET BETWEEN HINGE LUGS.
1
8
4 9
6
5
3
2
7
