Operating Manual - digiMIX18 Digital Mixer
HPF and LPF lter types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Bypass, Butterworth (BW) 6dB/oct, Bessel (BS) 6dB/oct,
BW 12dB/oct, BS 12dB/oct, Linkowitz/Riley (LR) 12dB/oct,
BW 18dB/oct, BS 18dB/oct, BW 24dB/oct, BS 24dB/oct,
LR 24dB/oct, BW 30dB/oct, BS 30dB/oct, BW 36dB/oct,
BS 36dB/oct, LR 36dB/oct, BW 42dB/oct, BS 42dB/oct,
BW 48dB/oct, BS 48dB/oct, LR 48dB/oct
GEQ (graphic EQ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Main L/R, aux1-8 outputs
Filter type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 band, constant Q, boost/cut ±24dB
FX (effects) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .FX1-2 input Sends from all 18 inputs,
FX1-2 output Assigns to main L/R, aux1-8
Effect types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Reverbs (3), delay (1200ms), tremolo, ange, chorus, combinations
See chart in section 4.6 for complete effects details
Automixer (for speech only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Gain-sharing type, individual assignment of channels 1-16
Crossfade mode (system screen) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Use pan control to fade between any two assigned inputs, outputs, or FX
Stereo link. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Inputs 1-16, aux1-8 outputs, paired only as 1-2, 3-4, 5-6 etc.
DCA groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 groups, level, mute, solo
Password Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Mixer lock, unlock, 4-character password, case sensitive
EZ Mode (simplied individual fader adjust, on/off, icon assign) . . . . . EZ Mixer #1: Main L/R, DCA1-4, aux1-4, password lock
EZ Mixer #2: Main L/R, DCA1-6, aux1-8, ch17-18, password lock
Preset types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Scene (24), DSP channel (48), FX (104), GEQ (48)
A-D converter dynamic range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104dB, unweighted
Internal processor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-bit oating point
D-A converter dynamic range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105dB, unweighted
ADC/DAC bit depth and sampling rate . . . . . . . . . . . . . . . . . . . . . . . . . . .24-bit / 48kHz
Latency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.8mS, 1kHz, analog input to analog output
Optional digital audio modules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Dante-3018, USB-3018 (eld installable)
Dante-3018 bit depth, sampling rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24bit, 48kHz
USB-3018 bit depth, sampling rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24bit, 48kHz
DigiMIX18 digital in, ch1-18 (pre-DSP). . . . . . . . . . . . . . . . . . . . . . . . . . On/Off, level control +10dB to -70dB, off, xed channel mapping
DigiMIX18 digital out ch1-16 (selectable as group pre or *post DSP). . .On/Off, +10dB to -70dB level, xed channel mapping
DigiMIX18 digital out ch17-18, main L/R, aux1-8. solo (post DSP only). . On/Off, +10dB to -70dB level, xed channel mapping
*Note: Digital in and out can not be used simultaneously for the same channel if digital out is set to post DSP.
Software/Utilities/Drivers
Remote mixer control app for iPad
®
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . "Ashly digiMIX" app, free from iTunes App Store
Firmware update software for Windows or Mac . . . . . . . . . . . . . . . . . . . . "digiMIX18 Firmware Utility" a vailable on Ashly website
Preset backup/restore for Windows or Mac. . . . . . . . . . . . . . . . . . . . . . . . "digiMIX18 Preset Utility" a vailable on Ashly website
USB COM device driver for connecting digiMIX18 utility (if required) Available on Ashly website for Windows or Mac
ASIO driver (required if using USB-3018 option with Windows) . . . . . . Available on Ashly website for Windows, not required for Mac
MAC address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .printed on serial number sticker on back of mixer
Ethernet communication defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IP 192.168.2.1, auto-DHCP, port 5000, uses both UDP and TCP/IP
AC mains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100-240VAC 50/60Hz, 120W max
Operating free-air temperature range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41°F ~ 113°F (5°C ~ 45°C)
Storage temperature range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -4°F ~ 140°F (-20°C ~ 60°C)
Unit dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19.3"L x 5.65"W x 14.0"H (48.6cm x 14.4cm x 35.6cm)
Shipping dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22.0"L x 8.15"W x 17.1"H (55.9cm x 20.7cm x 43.4cm)
Unit weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17.0 lbs (7.7kg)
Shipping weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21.0 lbs (9.5kg)
Dante-3018 shipping weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.42 lbs (0.19kg)
Dante-3018 shipping dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6.02"L x 1.85"W x 7.09"H (15.3cm x 4.70cm x 18.0cm)
USB-3018 shipping weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.47 lbs (0.21kg)
USB-3018 shipping dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6.02"L x 1.85"W x 7.09"H (15.3cm x 4.70cm x 18.0cm)
Compliance/safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . cTUVus, CE, FCC, RoHs
Limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 year (3 year on touchscreen and motorized fader)

Ashly digiMIX18 Specifications

General

Brand	Ashly
Model	digiMIX18
Category	Music Mixer
Language	English
