Ashton MXL12FX - Headphone Plugs

PAGE 12
HeADPHone PLUGs
The foot switch connects the two poles momentarily
Unbalanced use of
¼" TRS connector
Balanced use of
¼" TRS connector
Headphones connection
with ¼" TRS connector
¼" mono plug
¼" stereo plug
stereo plug for headphones connection
strain relief clamp
strain relief clamp
strain relief clamp
sleeve
sleeve
sleeve
tip
tip
tip
ring
ring
tip
signal
tip
hot(+ve)
tip
left signal
ring
cold(-ve)
ring
right signal
sleeve
ground shield
sleeve
ground shield
sleeve
ground shield
Forconnectionofbalancedandunbalancedplus,
rig and sleeve have to be bridged at the stero plug
