PAGE 7
DIGItAL eFFeCts PRoCessoR
Note:NeveruseunbalancedXLRconnectors(PIN1to3connected)ontheMICinput
connectorswhenusingphantompowersupply.Connectmicsandmutemonitor/PA
loudspeakersBEFOREswitchingonphantompowersupply.
7. PHONES: This adjusts the levels of the headphones.
8. FX TO MAIN: This feeds the effects signal into the main mix. If the control is turned all
thewaycounter-clockwise,noeffectssignalispresentinthesignalofthemixingconsole.
9. CLIP/SIGNAL LED: IfthisLEDisconstantlyon,itmeansthattheeffectsprocessoris
overdriven which results in distortion.
10. FX PROGRAM: Turn the program control to dial in an fx program number program
number. The number of the preset dialed in will blink in the display. To confirm
selection, press the program control and the blinking will stop.
