PAGE 10
ASSEMBLY
7. ATTACHING THE KICK TRIGGER:
i) Attach the rod to the holders.
ii) Attach the kick pedal to the kick pad.
iii) Tighten the wing screw on the kick pedal.
iv) Loosen the screw.
v) Attach the beater to the kick pedal.
vi) Center the beater to the pedal and tighten the screw.
SETTING UP THE
