USER GUIDE XGA LCD PROJECTOR
38
12.2 PROJECTOR UNIT
PROJECTOR DIMENSIONS
(H x W x L)
118 x 262 x 312 (399 incl. lens) mm
4.6 x 10.3 x 12.3 (15.7incl. lens) inch
PROJECTOR WEIGHT 4.9 kg / 10.8 lbs.
PROJECTION LENS Manual zoom and focus lens
1.3 zoom ratio
f 45-59 mm
F 2.0 – 2.3
IMAGE SIZE 0.76 - 7.62 m / 30 - 300 inches
(wide)
0.58 - 5.84 m / 23 - 230 inches
(Tele)
PROJECTION DISTANCE 1.2 - 12 m / 3.9 – 39.3 ft
ANTI-KEYSTONE CORRECTION 12 degrees
PROJECTION LAMP 120 W UHP
LIGHT OUTPUT 1200 ANSI lumen
LIGHT VALVE 1.3” polysilicon TFT LCD
COLOR RESOLUTION 16.7 MILLION
CONTRAST RATIO 300:1
PIXEL RESOLUTION 1024 x 768 x 3
DEFECTIVE PIXELS 10 (max)
VIDEO FREQUENCY 12 - 150 MHz
HORIZONTAL SYNC 15 - 100 Hz
VERTICAL SYNC 43.5 - 130 Hz
COMPUTER INPUT 0 - 1 Vpp
AUDIO INPUT 1V RMS
SPEAKERS 2 x 5 W speakers
CONFORMANCE
• CE
• UL
• cUL
• FCC, Subpart J, Part 15
12.3 POWER SUPPLY
DUAL VOLTAGE 100 - 120 VAC, 60 Hz, +/- 10 %
220 - 240 VAC, 50 Hz, +/- 10 %
250 W operating
