USER GUIDE XGA LCD PROJECTOR
41
13 CONNECTORS
The pinouts of all the connector ports is described in this section.
Connector panel
Do not connect any devices or cables other than those
supplied with the projector into the connector ports on the
projector unit, even if the connector ports appear identical,
as this voids any warranty and may cause permanent
damage to the projector.
13.1 SOURCE 1 & 2
This connector relays all signals from the computer to the projector, and
also back to a local CRT monitor if required.
1
2
3
ANALOG R IN
ANALOG G IN
ANALOG B IN
7
8
ANALOG R OUT
1
10
19
9
18
26
26 PIN HIGH DENSITY DSUB
FEMALE (FRONT VIEW)
9
10
11
12
ANALOG G OUT
ANALOG B OUT
ANALOG R GND IN
ANALOG G GND IN
ANALOG B GND IN
16
17
18
19
20
21
ANALOG R GND OUT
ANALOG G GND OUT
ANALOG B GND OUT
HSYNC IN
24
25
26
C/VSYNC IN
DIGITAL GND
DIGITAL GND
HSYNC OUT
VSYNC OUT
22 RESERVED
23
RESERVED
4
RESERVED
5 RESERVED
6 RESERVED
13
14
15
RESERVED
RESERVED
RESERVED
AUDIO OUT
RS-232 AUDIO 1 SOURCE 1MOUSE 1 AUDIO 2 SOURCE 2
REMOTE
USB MOUSE 2
