Specifications are subject to change without notice. See installation instructions for additional details.
23
DIMENSIONS
US Metric
Height 67"–69" 1702–1753 mm
Width 23-7/16" 595mm
Depth 24-7/16" 621 mm
Weight 253–258 lbs 115–117 kg
WARNING! Never stack a washer on top of a dryer!
Any ASKO dryer can be mounted on top of any matching
ASKO washer. Stacking kits are packed inside the dryer. Refer
to the ASKO Dryer Use and Care Guide for stacking instructions.
Every ASKO washer is delivered ready-fitted with a plug and is
intended for connection to an ASKO dryer, which is equipped with
a matching receptacle. When an ASKO washer is connected to the
dryer, use 220 V, 30 Amp single-phase circuit. When the dryer is
W6021/W6441 AND T701 VENTED DRYER
on a separate outlet, use 220 V, 15 Amp single-phase circuit. If
the washer is used separately or with another dryer, it must be on
a separate 220 V, 20 Amp single-phase circuit.
When placing a stacked set next to a wall or cabinet, be sure to
leave 1/2" (12 mm) of space between the washer and the wall
or cabinet.
See page 18 for venting requirements.
See pages 29 for stacked cabinet or closet dimensions.
WARNING! To reduce the risk of fire, vented dryers
must be exhausted OUTDOORS or the equivalent.
Never cover the end of the dryer stub or vent hose with
anything to catch lint, except for a UL-approved vent
basket.
ASKO STACKED LAUNDRY PAIRS
