30
ASKO LAUNDRY
CUTOUT DIMENSIONS
US Metric
Height 68" to 70" 1727 to 1778 mm
Width 24-1/2" minimum 622 mm
Depth 25" 635 mm
NOTE: For these installations, a custom countertop may be required.
SIDE-BY-SIDE UNDER-COUNTER INSTALLATIONS
ASKO’s front panel controls make it possible to install the washers
and dryers under a cabinet or in a closet. Make sure there is a
1/2" (12 mm) minimum clearance between units and between
units and cabinet or wall.
Every ASKO washer is delivered ready-fitted with a plug and is
intended for connection to an ASKO dryer, which is equipped with
a matching receptacle. When an ASKO washer is connected to
the dryer, use 220 V, 30 Amp single-phase circuit. When the dryer
is on a separate outlet, use 220 V, 15 Amp single-phase circuit. If
the washer is used separately or with another dryer, it must be on
a separate 220 V, 20 Amp single-phase circuit.
NOTE: To avoid crimping the electrical and water
connections, do not install the hookups between
the area of 26" to 35" from the floor.
OPENING FOR WASHER AND
VENTED DRYER
T701 and T721 dryers can be vented from the rear or the
left or right side. The cabinet cutout illustrated at right
gives the dimensions for a rear and left exhaust. See
page 18 for venting requirements.
WARNING! To reduce the risk of fire, vented
dryers must be exhausted OUTDOORS or the
equivalent.
Never cover the end of the dryer stub or vent
hose with anything to catch lint, except for a
UL-approved vent basket.
OPENING FOR WASHER AND
CONDENSER DRYER
ASKO condenser dryers can be installed to continuously
drain through a hose attached to the rear of the machine.
To ensure proper drainage, the drain must not be
higher than 40" above the bottom of the dryer. See
page 19 for condensation drain requirements.
