26
Drain pump
The pump can be accessed from inside the
machine.
1. Cut the power to the machine by pulling
out the plug!
2. Remove the coarse filter and pipe
section.
3. Remove the small fitted piece at the left of
the bottom drain (see the image below).
4. You can release and turn the pump blade
by inserting your finger into the hole and
release anything blocking it.
5. Reinstall the fitted piece and filters.
6. Plug the plug into the wall socket.
If the machine still does not start and a
buzzing sound is heard, the overflow guard
has been activated.
• Shut off the water.
• Pull the plug out from the wall socket.
• Call the service division.
NOTE!
Do not forget to reinstall the fitted piece.
The spray arms
Holes and bearings can sometimes become
blocked.
1. Pull the lower washer arm straight up to
release it.
2. Remove any deposits using a needle or
similar.
The washer arms also have holes under
neath.
Cleaning
