Fitting the dishwasher in place
7. Lift the dishwasher a little at the front and
turn the front feet to lower them.
8. Check that there is a space of 1/8 inch (3
mm) between the top of the dishwasher door
and the underside of the worktop.
Do not attach the mounting screws. This will
be done later.
3 mm
1/8
”
9. Adjust the back foot by turning the adjustment
screw at the front clockwise.
