Top spray arm
• The upper basket must be removed before the top spray arm can be released. Extend the upper
basket then rotate the basket catch on each runner outward (see illustration). Remove the basket.
• Pull out the top cutlery tray. Push the top spray arm up and turn the spray arm bearings counter-
clockwise to remove the spray arm.
Upper spray arm
1. Pull out the upper basket.
2. Unscrew the spray arm bearings counterclockwise to remove the spray arm from the upper
basket.
Lower spray arm
• Pull the lower spray arm straight up to release it.
27
Care and maintenance instructions
