Service manual DW90
16
Component description
Heating Water Circuit (HWC)
A certain type of machine is adapted for
connection to the building’s existing hot water
supply to reduce energy consumption.
The function settings for these machines are
changed via the service menu.
Humidity sensor
The humidity sensor is located in the fan
housing. The sensor is of the capacitive type
and measures relative humidity. The humidity
sensor measures the ambient humidity before
the drying program begins and controls the
drying time until it senses a humidity level close
to that before the drying program began.
Purpose: To make sure the drying program
runs as long as necessary to ensure a
satisfactory drying result.
Status Light™
To the right at the bottom edge of the door
is a light that communicates in three different
colours to indicate the machine’s status.
BLUE - The program has started, but you
can still load more dishes into the machine (no
detergent in the machine).
RED - Constant red light; loading more dishes
into the machine not recommended (detergent
in the machine). Flashing red light indicates a
fault. This can mean a water inlet fault, leaking
valve, overflow or water outlet fault. In case of
fault, see the troubleshooting section.
GREEN - The program has finished, unload
the machine.
