SERVICE
1
2
2
Changing the knobs (T700/720)
1. Remove the knobs by pulling them outwards.
IMPORTANT
Position the knobs with their markings facing up.
NOTE
It is possible to use a polygrip (mole wrench) to
remove the knobs, but in that case remember to
put some soft material in the jaws so as not to
scratch the plastic.
2. Fit the new knobs.
Changing the panel handle
1. Remove the three screws at the rear edge and
lift off the top cover.
2. T700/760: Unscrew the 2 screws securing the
front rail.
3. Pull the handle off.
4. Fit the handle.
5. Fit the top cover.
IMPORTANT
Don't forget the 2 star washers for the outermost
screws.
Changing the indication lamp/symbol lens
1. Remove the panel in accordance with the sec-
tion "Panel - removing...".
2. Change the indication lamp/symbol lens.
3. Install the panel in accordance with the sec-
tion "Panel - installation...".
