COMPONENTS AND MEASUREMENT VALUES
MOTOR
50 Hz
Part no.: 80 618 24
Resistance of winding
Cabel marked white-blue: 24,5 W
Cabel marked white-red: 26,5 W
Voltage: 220/240 V
Current: 1,1 A, 270 W, 2850 rpm
60 Hz
Part no.: 80 618 95
Resistance of winding
Cabel marked grey-blue: 25,5 W
Cabel marked grey-red: 16,0 W
Voltage: 220/240 V
Current: 0,9 A, 200 W, 3300 rpm
The 2-pole motor is connected directly to the fan
for internal air, and via a gear to drive the drum.
On machines with condensers (TDC44) it also
drives the fan for external air.
All recistance values are ±7%.
CAPACITOR
Part no.: 80 542 68
The capacitor is located on the motor and has a
value of 8µF.
CONDENSATE WATER PUMP
HANNING
TDC44 25W
Part no.: 80 638 09
Resistance: 111 W
RADIO INTERFERENCE FILTER
Part no.: 80 585 58
Leakage current: 230 V/ 50 Hz 0.315 mA
The filter eliminates radio interference generated
by the machine.
INDICATION LAMP
Part no.: 80 070 73
Current: 1.68 mA, 230 V, 50 Hz
The lamp indicates that the main power switch is
set to on.
THERMISTOR
Part no.: 80 619 00
Resistance: 40-60 kW at 20°-30°C
The thermistor controls temperature regulation.
If the thermistor becomes short-circuited or dis-
connected from the control unit, the program
stops.
CONTACTOR
50 Hz
Part no.: 80 091 48
60 Hz
Part no.: 80 603 80
The contactor opens in case of overheating, when
the door is opened and at the end of the pro-
gram.
