25
Transport protection
Remove the three transport bolts and the plastic
plugs for locking the machine for transport
before using the machine.
1. Loosen and remove the bolts as illustrated
below.
2. To remove the plastic plugs that held the
bolts, squeeze together and pull out.
3. Remove the plastic covers from the plugs.
Push the plastic covers into the three holes
that contained the plugs. Save the plastic
plugs in case the machine is moved in the
future.
NOTE!
If the machine is to be transported, the bolts
and plastic plugs for locking the machine during
transport must be installed to prevent damage
to the machine through shaking. If the transport
bolts or plastic plugs have been lost, you can
order new ones from your retailer.
Article number Designation
80 882 77 Screw
80 901 05 Plastic plug, transport
lock
Order three of each item!
