Servicemanual WM60
35
Components and measurement values WM60
Item number Component Measurement value Comments
80 658 33 CIM-motor Resistanser:
Pin 1-3 stator 3,7 Ω
Pin 1-2 stator 3,6 Ω
Pin 2-3 rotor 3,6 Ω
Pin 4-5 tacho 178 Ω
80 617 06 Heating element
2000 W
28,4 Ω
80 014 74 Thermistor compl. with
holder
6.1-3.8 k
Ω (at room temperature 20 –
30°C/ 86°F)
The thermistor for temperature reading is located
between the motor cradle and the container.
The thermistor measures and controls the water
temperature that can vary from 0 to 90°C/ 194°F.
The element is disconnected if the thermistor is
short-circuited or disconnected from the program
control card.
88 012 63. Drain pump 50 Hz 144 Ω. The drain pump is combined with an integrated
fine filter trap, which can be cleaned by the user.
If the drain pump has run for 180 seconds during
draining, the program stops, resets and a fault code
is indicated in the display. The drain pumps capacity
is 20 liters/min.
88 012 64. Drain pump 60 Hz 76 Ω
80 762 02 EMC filter with inductor
50/60 Hz
680 kΩ The filter eliminates interference to and from the
machine.
80 838 80 Inlet valve 3,7 kΩ ± 0,5 kΩ 2 way inlet valve 8 litres / minute
80 798 73 Door lock 122 Ω The door lock is electro mechanical and equipped
with a magnet.
80 822 54 Control Unit WM60.3
80 822 55 Control Unit WM60.3 FI
80 822 58 Frequency converter w.
holder WM60.3, WM60.1
80 014 68 Control unit WM60.2
Components and measurement values
Temp, º C Resistance, Ohm
0 15806
10 9634
20 6046
25 4841
30 3900
40 2579
50 1744
60 1204
70 848
80 609
85 519
