CONTROLS AND INSTRUMENTS
SCOOTER OVERVIEW
eS1 RIGHT SIDE
A. Rear view mirror
B. Headlights
C. Turn indicator
D. Front LH reflector
E. Stand
F. Battery compartment
G. Seat
H. Seat hook
I. Tail light
J. License plate holder
K. Rear reflector
L. Engine
M. Front RH reflector
N. Ignition switch
eS1 LEFT SIDE
