ADJUSTMENTS AND PERIODIC MAINTENANCE
FRONT DISC BRAKE
The wear of disc and pads is automatically
compensated, therefore it has no effect on the operation
of the brake and does not require registration.
If there is excessive stroke and the lever is too close
to the grip when operating the brake, it could be due
to the presence of air in the circuit or to irregular
operation of the brake.
Effective braking action should begin after
approximately 1/3 of the brake lever stroke.
WARNING
In case of brake malfunctions check brake pad wear, if thickness is reduced both are
to be replaced at an authorized workshop.
WARNING
After replacing the pads operate the brake lever several times to reposition them
and bring the lever to the right position.
eS1 - eS2 eS3
