CONTROLS AND INSTRUMENTS
SCOOTER OVERVIEW
eS3 RIGHT SIDE
A. Rear view mirror
B. Headlights
C. Turn indicator
D. Front LH reflector
E. Stand
F. Battery compartment
G. Seat
H. Seat hook
I. Tail light
J. License plate holder
K. Rear reflector
L. Engine
M. Front RH reflector
N. Ignition switch
O. Passenger grab handle
P. Passenger pegs
eS3 LEFT SIDE
A
B
CD
E
F
G
H
I
J
K
L
M
N
O
P
