BATTERIES AND RECHARGE
DE
SL
HU
EN
CHARGING WITH BATTERY OUTBOARD
The charger can be removed to allow charging a
battery leaving the scooter the possibility to circulate
only with the other one.
Disconnect the battery cable by pressing on the two
side tabs of the connector and pull it out.
Remove the battery from the compartment using the
lifting handle.
Once removed, hold it with both hands.
