No. Description
1 3 x 288-pin DDR4 DIMM Slots (DDR4_J1, DDR4_K1, DDR4_L1)*
2 CPU2 Fan Connector (CPU2_FAN1)
3 ATX 12V Power Connector (ATX12V2)
4 ATX 12V Power Connector (ATX12V1)
5 ATX Power Connector (ATXPWR1)
6 PSU SMBus Header (PSU_SMB1)
7 3 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, DDR4_C1)*
8 LGA 3647 CPU Socket (CPU1)
9 3 x 288-pin DDR4 DIMM Slots (DDR4_D1, DDR4_E1, DDR4_F1)*
10 CPU1 Fan Connector (CPU1_FAN1)
11 Front Fan Connector (FRNT_FAN1)
12 Front Fan Connector (FRNT_FAN2)
13 Front Fan Connector (FRNT_FAN3)
14 Front Fan Connector (FRNT_FAN4)
15 System Panel Header (PANEL1)
16 SATA3 Connector (SATA_6), White
17 SATA3 Connector (SATA_7), White
18 SATA3 Connector (SATA_4), White
19 SATA3 Connector (SATA_5), White
20 SATA3 Connector (SATA_2), White
21 SATA3 Connector (SATA_3), White
22 SATA3 Connector (SATA_0), White
23 SATA3 Connector (SATA_1), White
24 SATA3 DOM Connector (SSATA_3), Red
25 SATA DOM Power Jumper (SATAPWR2)
26 M.2 Socket (M2_2) (Type 2230 / 2242 / 2260 / 2280)
27 SATA DOM Power Jumper (SATAPWR1)
28 SATA3 DOM Connector (SSATA_2), Red
29 Chassis ID1 Jumper (CHASSIS_ID1)
30 Chassis ID0 Jumper (CHASSIS_ID0)
31 Chassis ID2 Jumper (CHASSIS_ID2)
32 SATA3 Connector (SSATA_0), White
33 SATA SGPIO Connector (SATA_SGPIO1)
