EP2C621D12 WS
8 9
English
No. Description
34 SATA3 Connector (SSATA_1), White
35 SATA SGPIO Connector (SSATA_SGPIO1)
36 USB 3.0 Header (USB3_5_6)
37 ME Recovery Jumper (ME_RECOVERY1)
38 Vertical Type A USB 3.0 (USB3_1)
39 USB 2.0 Header (USB2_1)
40 TPM Header (TPM1)
41 Auxiliary Panel Header (AUX_PANEL1)
42 Speaker Header (SPEAKER1)
43 Intelligent Platform Management Bus header (IPMB_1)
44 BMC SMBus Header (BMC_SMB_1)
45 Front VGA Header (FRNT_VGA1)
46 Serial Port Header (COM1)
47 Front Panel Audio Header (HD_AUDIO1)
48 Front LAN LED Connector (FRONT_LED_LAN1)
49 SATA SGPIO Connector (SATA_SGPIO2)
50 Non Maskable Interrupt Button (NMI_BTN1)
51 M.2 Socket (M2_1) (Type 2230 / 2242 / 2260 / 2280)
52 Virtual RAID On CPU Header (RAID_1)
53 PWM Conguration Header (PWM_CFG1)
54 3 x 288-pin DDR4 DIMM Slots (DDR4_G1, DDR4_H1, DDR4_I1)*
55 Rear Fan Connector (REAR_FAN1)
56 LGA 3647 CPU Socket (CPU2)
*For DIMM installation and conguration instructions, please see p.21 (Installation of Memory Modules
(DIMM)) for more details.
