2.12 Hot Plug and Hot Swap F2.12 Hot Plug and Hot Swap F
2.12 Hot Plug and Hot Swap F2.12 Hot Plug and Hot Swap F
2.12 Hot Plug and Hot Swap F
unctions for SAunctions for SA
unctions for SAunctions for SA
unctions for SA
TT
TT
T
A / SAA / SA
A / SAA / SA
A / SA
TT
TT
T
AIIAII
AIIAII
AII
HDDs HDDs
HDDs HDDs
HDDs
This motherboard supports Hot Plug and Hot Swap functions for SATA / SATAII Devices
in RAID / AHCI mode. AMD SB710 south bridge chipset provides hardware support for
Advanced Host controller Interface (AHCI), a new programming interface for SATA host
controllers developed thru a joint industry effort. AHCI also provides usability enhancements
such as Hot Plug.
NOTE
What is Hot Plug Function?
If the SATA / SATAII HDDs are NOT set for RAID configuration, it is called
“Hot Plug” for the action to insert and remove the SATA / SATAII HDDs
while the system is still power-on and in working condition.
However, please note that it cannot perform Hot Plug if the OS has been
installed into the SATA / SATAII HDD.
What is Hot Swap Function?
If SATA / SATAII HDDs are built as RAID 1 then it is called “Hot Swap” for
the action to insert and remove the SATA / SATAII HDDs while the system
is still power-on and in working condition.
2.13 Hot Plug F2.13 Hot Plug F
2.13 Hot Plug F2.13 Hot Plug F
2.13 Hot Plug F
unction for SAunction for SA
unction for SAunction for SA
unction for SA
TT
TT
T
A3 HDDsA3 HDDs
A3 HDDsA3 HDDs
A3 HDDs
This motherboard supports Hot Plug functions for SATA3 Devices in AHCI mode. ASMedia
ASM1061 chipset provides hardware support for Advanced Host controller Interface (AHCI),
a new programming interface for SATA host controllers developed thru a joint industry
effort. AHCI also provides usability enhancements such as Hot Plug.
NOTE
What is Hot Plug Function?
If the SATA3 HDDs are NOT set for RAID configuration, it is called “Hot
Plug” for the action to insert and remove the SATA3 HDDs while the
system is still power-on and in working condition.
However, please note that it cannot perform Hot Plug if the OS has been
installed into the SATA3 HDD.
