48
Instant Flash
Instant Flash is a UEFI ash utility embedded in Flash ROM. This conve-
nient UEFI update tool allows you to update system UEFI without entering
operating systems rst like MS-DOS or Windows
®
. Just launch this tool
and save the new UEFI le to your USB ash drive, oppy disk or hard
drive, then you can update your UEFI only in a few clicks without prepar-
ing an additional oppy diskette or other complicated ash utility. Please
be noted that the USB ash drive or hard drive must use FAT32/16/12 le
system. If you execute Instant Flash utility, the utility will show the UEFI
les and their respective information. Select the proper UEFI le to update
your UEFI, and reboot your system after UEFI update process completes.
3.4 Advanced Screen
In this section, you may set the con gurations for the following items: CPU Con gu-
ration, Nouth Bridge Con guration, South Bridge Con guration, Storage Con gura-
tion, Super IO Con guration, ACPI Con guration, and USB Con guration.
Setting wrong values in this section may cause
the system to malfunction.

Table of Contents

Other manuals for ASROCK A75 Pro4-M

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK A75 Pro4-M and is the answer not in the manual?

ASROCK A75 Pro4-M Specifications

General IconGeneral
Form FactorMicro ATX
ChipsetAMD A75
SocketFM1
Max Memory64GB
PCIe Slots1 x PCIe 2.0 x16, 1 x PCIe 2.0 x1
PCI Slots2
SATA Ports6 x SATA3 6.0 Gb/s
Video OutputsD-Sub, DVI-D, HDMI
AudioRealtek ALC892 7.1-Channel High Definition Audio Codec
LANRealtek RTL8111E Gigabit LAN
Memory Slots4 x DIMM
Memory SupportDDR3 2400(OC)/1866/1600/1333/1066
eSATA Port1 x eSATA3
USB Ports10 x USB 2.0
RAID SupportRAID 0, RAID 1, RAID 10
