3.4.5 Super IO Configuration
Serial Port
Use this item to enable or disable the onboard serial port.
Serial Port Address
Use this item to set the address for the onboard serial port.
Con guration options: [3F8 / IRQ4] and [3E8 / IRQ4].
Infrared Port
Use this item to enable or disable the onboard infrared port.
Infrared Port Address
Use this item to set the address for the onboard infrared port.
Con guration options: [2F8 / IRQ3] and [2E8 / IRQ3].
Parallel Port
Use this item to enable or disable the onboard parallel port.
Device Mode
Use this item to change the Printer Port mode.
Change Settings
Use this item to select an optional setting for Super IO device.

ASROCK A75 Pro4-M Specifications

General

Form Factor	Micro ATX
Chipset	AMD A75
Socket	FM1
Max Memory	64GB
PCIe Slots	1 x PCIe 2.0 x16, 1 x PCIe 2.0 x1
PCI Slots	2
SATA Ports	6 x SATA3 6.0 Gb/s
Video Outputs	D-Sub, DVI-D, HDMI
Audio	Realtek ALC892 7.1-Channel High Definition Audio Codec
LAN	Realtek RTL8111E Gigabit LAN
Memory Slots	4 x DIMM
Memory Support	DDR3 2400(OC)/1866/1600/1333/1066
eSATA Port	1 x eSATA3
USB Ports	10 x USB 2.0
RAID Support	RAID 0, RAID 1, RAID 10
