62
Installing OS on a HDD Larger Than 2TB
This motherboard is adopting UEFI BIOS that allows Windows
®
OS to be installed
on a large size HDD (>2TB). Please follow below procedure to install the operating
system.
1. Please make sure to use Windows
®
Vista
TM
64-bit (with SP1 or above) or
Windows
®
7 64-bit.
2. Press <F2> or <Delete> at system POST. Set AHCI Mode in UEFI Setup Utility >
Advanced > Storage Con guration > SATA Mode.
3. Choose the item “UEFI:xxx“ to boot in UEFI Setup Utility > Boot > Boot Option #1.
(“xxx” is the device which contains your Windows
®
installation les. Normally it is
an optical drive.) You can also press <F11> to launch boot menu at system POST
and choose the item “UEFI:xxx“ to boot.
4. Start Windows
®
installation.

Table of Contents

Other manuals for ASROCK A75 Pro4-M

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK A75 Pro4-M and is the answer not in the manual?

ASROCK A75 Pro4-M Specifications

General IconGeneral
Form FactorMicro ATX
ChipsetAMD A75
SocketFM1
Max Memory64GB
PCIe Slots1 x PCIe 2.0 x16, 1 x PCIe 2.0 x1
PCI Slots2
SATA Ports6 x SATA3 6.0 Gb/s
Video OutputsD-Sub, DVI-D, HDMI
AudioRealtek ALC892 7.1-Channel High Definition Audio Codec
LANRealtek RTL8111E Gigabit LAN
Memory Slots4 x DIMM
Memory SupportDDR3 2400(OC)/1866/1600/1333/1066
eSATA Port1 x eSATA3
USB Ports10 x USB 2.0
RAID SupportRAID 0, RAID 1, RAID 10
