57
AMD X670/B650/A620 Series
MBIST Test Mode
Allows you to select MBIST Test Mode - Interface Mode (Tests Single and Multiple CS
transactions and Basic Connectivity) or Data Eye Mode (Measure Volage vs. Timing).
Conguration options: [Auto] [Interface Mode] [Data Eye Mode] [Both]
MBIST Aggressors
Allows you to enable or disable MBIST aggressor test.
Conguration options: [Auto] [Disabled] [Enabled]
MBIST Per Bit Slave Die Reporting
When it is enabled, it reports 2D Data Eye Results in ABL Log for each DQ, Chipselect and
Channel.
Conguration options: [Auto] [Disabled] [Enabled]
DDR Data Eye
Press [Enter] to congure DDR Data Eye options.
Pattern Select
Allows you to congure Pattern Select.
Conguration options: [PRBS] [SSO] [Both]
Pattern Length
is token helps to determine the pattern length. e possible options are N=3...12.
Aggressor Channel
is helps to read the aggressors channels. If it is enabled, you can read from one or more
than one aggressor channel.
Conguration options: [Disabled] [1 Aggressor Channel] [3 Aggressor Channels] [7
Aggressor Channels]
DDR Memory Features
Press [Enter] to congure DDR Memory Features.
Memory Context Restore
Allows you to congure the mermoy context restore mode. When it is enabled, DRAM re-
retaining is avoided if possible and the POST latency is minimized.
Conguration options: [Auto] [Disabled] [Enabled]
NBIO Common Options
Press [Enter] to congure NBIO Common options.
IOMMU
Allows you to enable or disable IOMMU.
Conguration options: [Auto] [Disabled] [Enabled]
