ASROCK B75M Quick Installation Guide

68
ASRock B75M Motherboard
1.2 Specifiche
Piattaforma - Micro ATX Form Factor: 9.6-in x 8.4-in, 24.4 cm x 21.3 cm
- Design condensatore robusto
Processore - Supporta Intel
®
Core
TM
i7 / i5 / i3 di 3a e 2a generazione in un
pacchetto LGA1155
- Struttura di fase con alimentazione 3 + 1
- Supporta della tecnologia Intel
®
Turbo Boost 2.0
- Supporta CPU unlocked serie K (vedi ATTENZIONE 1)
- Supporta tecnologia Hyper Threading (vedi ATTENZIONE 2)
- Supporta tecnologia Intel
®
Rapid Start Technology e Smart
Connect Technology con CPU Intel
®
Ivy Bridge
Chipset - Intel
®
B75
- Supporta Intel
®
Small Business Advantage
(vedi ATTENZIONE 3)
Memoria - Supporta tecnologia Dual Channel Memory
(vedi ATTENZIONE 4)
- 2 x slots DDR3 DIMM
- Supporta DDR3 1600/1333/1066 non-ECC, momoria senza
buffer (DDR3 1600 con CPU Intel
®
Ivy Bridge, DDR3 1333 con
CPU Intel
®
Sandy Bridge)
- Capacità massima della memoria di sistema: 16GB
(vedi ATTENZIONE 5)
- Supporta di Intel
®
XMP (Extreme Memory Prole)1.3/1.2
Slot di - 1 x Alloggio PCI Express 3.0 x16 (PCIE1: modalità x16)
(vedi ATTENZIONE 6)
* PCIE 3.0 è supportato soltanto con la CPU Intel
®
Ivy Bridge.
Con la CPU Intel
®
Sandy Bridge, supporta solamente PCIE
2.0.
- 1 x Alloggio PCI Express 2.0 x16 (PCIE2 : modalità x4)
- 2 x Alloggio PCI
- Supporta di AMD Quad CrossFireX
TM
e CrossFireX
TM
VGA su scheda * Le uscite Intel
®
HD Graphics Built-in Visuals e VGA possono
essere supportate solo con processori dotati di GPU integrata.
- Supporta Intel
®
HD Graphics Built-in Visuals: Intel
®
Quick Sync
Video 2.0, Intel
®
InTru
TM
3D, Intel
®
Clear Video HD Technology,
Intel
®
Insider
TM
, Intel
®
HD Graphics 2500/4000
- Pixel Shader 5.0, DirectX 11 con CPU Intel
®
Ivy Bridge, Pixel
Shader 4.1, DirectX 10.1 con CPU Intel
®
Sandy Bridge
- Memoria massima condivisa 1760MB (vedi ATTENZIONE 7)
- Tre opzioni d’output VGA: D-Sub, DVI-D e HDMI
Italiano

ASROCK B75M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Supported memory module capacities	1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Number of SATA II connectors	5
Number of SATA III connectors	3
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
HDMI version	1.4a
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Audio chip	Realtek ALC662
Cooling type	Passive
Certification	FCC, CE, WHQL, ErP/EuP Ready
Component for	PC
Power source type	ATX
Motherboard chipset	Intel B75
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7, Vista, XP 32/64-bit
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	GMA X4500
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1760 MB
Parallel processing technology support	2-Way CrossFireX, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
Controller 2nd interface type	ASMedia ASM1061
LAN controller	Realtek RTL8111E
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	1.1
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	213 mm
Width	244 mm
