ASRock B75M Motherboard
(vedi ATTENZIONE 8)
- Supporta HDMI 1.4a con risoluzione massima no a
1920x1200 @ 60Hz
- Supporta DVI con risoluzione massima no a 1920x1200 @
60Hz
- Supporta D-Sub con risoluzione massima no a 2048x1536 @
75Hz
- Supporta delle funzioni Auto Lip Sync, Deep Color (12bpc),
xvYCC e HBR (High Bit Rate Audio) con HDMI (è necessario
un monitor compatibile HDMI) (vedi ATTENZIONE 9)
- Supporta della funzione HDCP con le porte DVI e HDMI
- Supporta 1080p Blu-ray (BD) / HD-DVD riproduzione con le
porte DVI e HDMI
Audio - 5.1 CH HD Audio (Realtek ALC662 Audio Codec)
- Supporto THX TruStudio
TM
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111E
- Supporta Wake-On-LAN
- Supporta il rilevamento cavo LAN
- Supporta di Energy Efcient Ethernet 802.3az
- Supporta PXE
Pannello I/O Panel
posteriore I/O - 1 x porta PS/2 per mouse
- 1 x porta PS/2 per tastiera
- 1 x Porta D-Sub
- 1 x Porta DVI-D
- 1 x Porta HDMI
- 2 x porte USB 2.0 già integrate
- 4 x porte USB 3.0 già integrate
- 1 x porte LAN RJ-45 con LED (LED azione/collegamento e
LED velocità)
- Connettore HD Audio: ingresso linea / cassa frontale /
microfono
SATA3 - 1 x Connettori SATA3 6,0Gb/s B75 Intel
®
, supporta delle
funzioni NCQ, AHCI e Hot Plug
- 2 x Connettori SATA3 6,0Gb/s ASM1061 ASMedia, supporta
delle funzioni NCQ, AHCI e Hot Plug
USB 3.0 - 4 x porte USB 3.0 posteriori amministrate dal controller,
supporta di USB 1.0/2.0/3.0 no a 5Gb/s
Connettori - 5 x connettori SATA2 3.0Go/s, sopporta delle funzioni NCQ,
AHCI e Hot Plug
Italiano
